Pentair 7.81″ Center Push Pull Valve | 263053

Description

Pentair 263053 Push-Pull Slide Valve2 Ports, 7.81 Centerline

Part Number: 263053

A two-position push-pull backwash and filtration valve designed for use with either D.E. or sand filters. Features 2 port connections and a centerline dimension of 7.81 to align with filter inlet/outlet locations.

Compatibility & Fitment

• Fits many Pentair/Sta-Rite modular filters specified for this valve geometryaccepts 2 plumbing and side-port connections.
• Ideal when the existing valve shows leaks, handle operation is difficult, or the valve cannot be serviced effectively.
• Direct replacement for systems listing part number 263053.

Features & Specifications

• Function: Two-position (FILTER and BACKWASH) push-pull style handle for quick service changeover.
• Port size: 2 (union-style or slip/union depending on installation).
• Centerline between filter ports: approximately 7.81.
• Includes unions for connection to filter tank side ports.
• Constructed of ABS or pool-rated plastic suitable for D.E. and sand systems.

Installation Notes

Turn off the filter pump and relieve system pressure. Backwash or drain the filter tank if required. Remove the old valve assembly, clean and inspect the filters port openings and sealing surfaces. Install the new 263053 push-pull valve, align the ports correctly, secure unions and connections per manufacturer guidelines, restore circulation and test both filtration and backwash settings for proper flow and sealing.

Maintenance Tip

Inspect this valve each service interval. Check for leaks, ease of handle movement, and wear in seals or union joints. Replace immediately if operation becomes sticky, flow is restricted, or the valve leaks during use to maintain optimal filter performance.
