Century (A.O. Smith) 0.75 HP Up-Rate Pool Pump Motor – B2852Square Flange | 56Y Frame | Single Speed

Description

Top

Part  B852

Warranty 1 Year

Manufacturer Code B2852

Dimensions 12″ L x 8″ W x 6.5″ D

Alternate Part ‘s 0-193984-25, 10-177214-24, 1103645400, 168451, 16858, 177214, 17721400, 177842, 177970, 1863580J, 187331, 193266, 193984, 196232, 196237, 196248, 355018S, 54002, 5KC36MN2533BX, 5KC36MN2533X, 7-177214-24, 7-186236-20, 7-193266-20, 717721424, 8-177214-24, 8-177970-20, 8-193266-20, 90106915, A0104800, A100DL, A100DLL, B2852, B691, C1244, C48AB44A01, C48J2EC105, EB852, F56AA36A01, P716, SQ107U, SQD75UP1, USQ1072, V54002, AOSB2852, CRMB2852

Product Description

Century and Magnetek replacement motors for your swimming pool pumps. INYOpools.com is one the largest pool pump replacement motor retailers in the world. Our replacement pool motors are made to all of the top manufacturers specifications. We stock thousands of motors which are designed to work on pool and spa pumps from manufactures like: Sta-Rite, Pac Fab, Hayward, Purex, American Products, Jandy, Jacuzzi, and more. If you need assistance choosing the proper replacement motor for your pump, feel free to use our Live Chat feature.

Compatible With

• Sta-Rite SuperMax Model PHK2RA6D-101L

Other Options Replacement Options:

• 2-Speed 230V – Model B2980
• 2-Speed 115V – Model B2981
• Variable Speed 230/115V – EVQ165

Motor DimensionsMotor Image

Product Specifications

Motor Name:3/4 HP B852/B2852 Replacement Pool MotorHP:.75 HPSpeed:SingleRPM:3450 RPMVolts:230/115 VAmps:10.8/5.4 ampService Factor:1.25Total HP:.94 HPFrame:P56YStock :B852/B2852Shaft:ThreadedOverload Protector:AutoDimension Letter:CDimensions:12.4 in.Commonly Used On:Sta-Rite: Max-E-Glas, Max-E-Glas II, Dura-Glas, Dura-Glas II, Dyna-Glas, Dyna-Max. Pentair: Whisperflo, Challenger, Pinnacle and Anthony AR2 SeriesModel:Whisperflo & ChallengerPump Model:WF-23 & CFII-NI-3/4A
